Uwagi do procesora: Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max, Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types
Format płyty: Micro-ATX
BIOS: 128 Mb Flash ROM, UEFI AMI BIOS
Chipset płyty głównej: Intel® H610
Ilość złącz pamięci DDR4: 2
Maksymalna wielkość pamięci: 96 GB
Tryb pracy pamięci RAM: Dual Channel
Standard pamięci: DDR5-4800, DDR5-5000, DDR5-5200, DDR5-5400, DDR5-5600
Uwagi do pamięci RAM: Supports Intel® Extreme Memory Profile (XMP), Supported memory types, data rate (speed), and number of DRAM modules vary, depending on the CPU and memory configuration, for more information please, refer to CPU/Memory Support list under the Support tab of product, Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
Zintegrowany kontroler SATA: Chipset: 4x SATA III 6Gb/s + 1x M.2
Uwagi do kontrolera SATA: M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)
Wbudowana karta graficzna: Brak lub Intel® UHD Graphics 730/750/770/Iris Xe (zależy od procesora)
Gniazda karty graficznej: HDMI, VGA, DisplayPort
Uwagi do karty graficznej: Graphics specifications may vary between CPU types. Please refer to, Supports max. 4K@60Hz as specified in DisplayPort 1.4., Supports 4K@60Hz as specified in HDMITM 2.1.
Zintegrowana karta dźwiękowa: Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Uwagi do karty dźwiękowej: - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking, - Supports up to 24-Bit/192 kHz playback, - Audio Shielding, - Premium audio capacitors, - Dedicated audio PCB layers
Złącza PCI Express x16: 1
Złącza PCI Express x1: 1
Uwagi do złącz PCI: Intel® Core™ Processors (14th & 13th & 12th Gen):, - 1 x PCIe 4.0 x16 slot (supports x16 mode), Intel® H610 Chipset:, - 1 x PCIe 3.0 x1 slot
Port LAN: 1x Gigabit LAN 100/1000 Mb/s (Intel®)
Maksymalna ilość portów USB 2.0: 6
Maksymalna ilość portów USB 3.x: 4
Porty USB na panelu tylnym: 2x USB 2.0 + 2x USB 3.0
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty)
Port PS/2: Port klawiatury PS/2, Port myszy PS/2
Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
Port równoległy (LPT): 1x wewnętrzne gniazdo portu LPT
Inne porty i gniazda: 4-pin CPU Fan header, 4-pin Chassis Fan header, Clear CMOS button(s), Chassis intrusion header, SPI TPM header (14-1pin), 10-1 pin System Panel header
Gniazdo zasilania: ATX (24-pin) + ATX12V (4-pin)
Wymiary [S x W] (mm): 226 x 195
Opakowanie: BOX
Wyposażenie dodatkowe: 2 x SATA 6Gb/s cables, 1 x I/O shield, 1 x M.2 anchor, 1 x User guide
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Windows® 11 64-bit, Windows® 10 64-bit
- Audio Shielding, - Dedicated audio PCB layers, - Premium audio capacitors, - Supports up to 24-Bit/192 kHz playback, - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
Uwagi do karty graficznej:
Graphics specifications may vary between CPU types. Please refer to, Supports 4K@60Hz as specified in HDMITM 2.1., Supports max. 4K@60Hz as specified in DisplayPort 1.4.
Uwagi do kontrolera SATA:
M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)
Uwagi do pamięci RAM:
depending on the CPU and memory configuration, for more information please, Non-ECC, un-buffered DDR5 memory supports On-Die ECC function., refer to CPU/Memory Support list under the Support tab of product, Supported memory types, data rate (speed), and number of DRAM modules vary, Supports Intel® Extreme Memory Profile (XMP)
Uwagi do procesora:
Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types, Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max
