Uwagi do pamięci RAM: Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Extreme Memory Profile (XMP) memory modules
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 3x M.2 - RAID 0, 1, 10
Uwagi do kontrolera SATA: CPU:, - 1x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0 x4/x2 SSD, support) (M2A_CPU), - 1x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD, support) (M2B_CPU), Chipset:, - 1x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD, support) (M2C_SB), - 4 x SATA 6Gb/s connectors
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI, DisplayPort
Uwagi do karty graficznej: 1x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 1.4 version and HDR, 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3, Support native HDMI 2.1 TMDS compatible ports, Graphics specifications may vary depending on CPU support
Zintegrowana karta dźwiękowa: Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Uwagi do złącz PCI: CPU:, - 1x PCI Express x16, supporting PCIe 4.0 and running at x16 (PCIEX16), Chipset:, - 2x PCI Express x16, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2)
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Maksymalna ilość portów USB 2.0: 8
Maksymalna ilość portów USB 3.x: 11
Porty USB na panelu tylnym: 4x USB 2.0 + 5x USB 3.0 + 2x USB 3.1 + 1x USB 3.1 Type-C
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.2 Type-C (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax
Port Bluetooth: Bluetooth V5.3
Uwagi do WiFi / BT: Realtek® Wi-Fi 6E RTL8852CE, Support for 11ax 160MHz wireless standard, Actual data rate may vary depending on environment and equipment
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: Clear CMOS header, Przycisk Reset, Gniazdo modułu TPM, 3x Addressable RGB Gen2 LED strip headers, CPU Fan, CPU fan/water cooling pump header
1x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Graphics specifications may vary depending on CPU support, Support for DisplayPort 1.4 version and HDR, Support for HDMI 2.1 version and HDCP 2.3, Support native HDMI 2.1 TMDS compatible ports
Uwagi do kontrolera SATA:
- 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0 x4/x2 SSD, - 1x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD, - 4 x SATA 6Gb/s connectors, Chipset:, CPU:, support) (M2A_CPU), support) (M2B_CPU), support) (M2C_SB)
Uwagi do pamięci RAM:
Extreme Memory Profile (XMP) memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Uwagi do procesora:
Support for: AMD Ryzen™ 7000 Series Processors
Uwagi do WiFi / BT:
Actual data rate may vary depending on environment and equipment, Realtek® Wi-Fi 6E RTL8852CE, Support for 11ax 160MHz wireless standard
Uwagi do złącz PCI:
- 1x PCI Express x16, supporting PCIe 4.0 and running at x16 (PCIEX16), - 2x PCI Express x16, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2), Chipset:, CPU:
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
305 x 244
Zintegrowana karta dźwiękowa:
Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 3x M.2 - RAID 0, 1, 10
Złącza PCI Express x16:
3
Dane producenta
Gigabyte Technology Co. Ltd.
NO. 6, BAO CHIANG ROAD
231 Xindian Dist., New Taipei
Taiwan
