Uwagi do pamięci RAM: Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Extreme Memory Profile (XMP) memory modules
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0,1,5,10
Uwagi do kontrolera SATA: 1x M.2 connector (M2A_CPU), , integrated in the CPU, supporting Socket 3,, M key, type 2580/2280 SSDs:, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, - 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3,, M key, type, type 25110/22110/2580/2280 SSDs:, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs, 4 x SATA 6Gb/s connectors:, RAID 5 is only available on AMD Ryzen™ 9000 Series Processors.
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI, 2x DisplayPort
Uwagi do karty graficznej: Integrated Graphics Processor with AMD Radeon™ Graphics support:, - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version, HDCP 2.3, and HDR, Support for native HDMI 2.1 TMDS compatible ports, - 2 x DisplayPorts, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 1.4 version, Graphics specifications may vary depending on CPU support, Support for up to quad-display at the same time
Zintegrowana karta dźwiękowa: Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Uwagi do karty dźwiękowej: You can change the functionality of an audio jack using the audio software, To configure 7.1-channel audio, access the audio software for audio setting
Złącza PCI Express x16: 2
Uwagi do złącz PCI: 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, The PCIEX16 slot can only support a graphics card or an NVMe SSD, If only one graphics card is to be installed, be sure to install it in, the PCIEX16 slot, Chipset:, - 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Maksymalna ilość portów USB 2.0: 8
Maksymalna ilość portów USB 3.x: 7
Porty USB na panelu tylnym: 4x USB 2.0 + 2x USB 3.0 + 1x USB 3.0 Type C
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
Port Wi-Fi: Nie
Port Bluetooth: Nie
Port PS/2: Port combo klawiatury/myszy PS/2
Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU fan header, CPU fan/water cooling pump header, System fan header, System fan/water cooling pump header, 2x Addressable RGB Gen2 LED strip header, RGB LED Header, Gniazdo modułu TPM, Reset jumper, Clear CMOS jumper, Q-Flash Plus button
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 244 x 244
Opakowanie: BOX
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Support for Q-Flash, Support for Q-Flash Plus, Support for Smart Backup, Support for Windows 10 and Windows 11 64-bit, Bundled Software:, - Norton® Internet Security (OEM version), - LAN bandwidth management software
Parametry:
BIOS:
256 Mbit flash AMI UEFI; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
Gniazdo procesora:
Socket AM5
Gniazdo zasilania:
ATX (24-pin) + ATX12V (8-pin)
Ilość złącz pamięci DDR5:
4
Inne porty i gniazda:
2x Addressable RGB Gen2 LED strip header, Clear CMOS jumper, CPU fan header, CPU fan/water cooling pump header, Gniazdo modułu TPM, Q-Flash Plus button, Reset jumper, RGB LED Header, System fan header, System fan/water cooling pump header
To configure 7.1-channel audio, access the audio software for audio setting, You can change the functionality of an audio jack using the audio software
Uwagi do karty graficznej:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, - 2 x DisplayPorts, supporting a maximum resolution of 3840x2160@144 Hz, Graphics specifications may vary depending on CPU support, Integrated Graphics Processor with AMD Radeon™ Graphics support:, Support for DisplayPort 1.4 version, Support for HDMI 2.1 version, HDCP 2.3, and HDR, Support for native HDMI 2.1 TMDS compatible ports, Support for up to quad-display at the same time
Uwagi do kontrolera SATA:
- 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3,, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs, 1x M.2 connector (M2A_CPU), , integrated in the CPU, supporting Socket 3,, 4 x SATA 6Gb/s connectors, M key, type 2580/2280 SSDs:, M key, type, type 25110/22110/2580/2280 SSDs:, RAID 5 is only available on AMD Ryzen™ 9000 Series Processors.
Uwagi do pamięci RAM:
Extreme Memory Profile (XMP) memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Uwagi do procesora:
AMD Ryzen™ 7000 Series Processors, AMD Ryzen™ 8000 Series Processors, AMD Ryzen™ 9000 Series Processors
Uwagi do złącz PCI:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4), - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x16 mode, 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU, Chipset:, If only one graphics card is to be installed, be sure to install it in, the PCIEX16 slot, The PCIEX16 slot can only support a graphics card or an NVMe SSD
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
244 x 244
Zintegrowana karta dźwiękowa:
Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0,1,5,10
Złącza PCI Express x16:
2
Zawiera baterię / akumulator:
Tak
