BIOS: 1 x 128 Mbit AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7,ACPI 5.0
Chipset płyty głównej: Intel® H610
Ilość złącz pamięci DDR5: 2
Maksymalna wielkość pamięci: 128 GB
Tryb pracy pamięci RAM: Dual Channel
Standard pamięci: DDR5-4400, DDR5-4800, DDR5-5200, DDR5-5600
Uwagi do pamięci RAM: Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, (operate in non-ECC mode), Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for Extreme Memory Profile (XMP), The CPU and memory configuration may affect the supported memory types,, data rate (speed), and number of DRAM modules, please refer to "Memory, Support List" on GIGABYTE's website for more information
Zintegrowany kontroler SATA: Chipset: 2x SATA III 6Gb/s + 1x M.2
Uwagi do kontrolera SATA: 1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD
Wbudowana karta graficzna: Intel® HD Graphics
Gniazda karty graficznej: DisplayPort, HDMI
Uwagi do karty graficznej: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, - Support for HDMI 2.1 version and HDCP 2.3, - Support native HDMI 2.1 TMDS compatible ports, 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz, - Support for DisplayPort 1.2 version and HDCP 2.3
Zintegrowana karta dźwiękowa: Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Uwagi do karty dźwiękowej: You can change the functionality of an audio jack using the audio software, To configure 7.1channel audio, access the audio software for audio settings
Złącza PCI Express x16: 1
Złącza PCI Express x1: 1
Uwagi do złącz PCI: CPU:, - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16, Chipset:, - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Port LAN: 1x 1 Gigabit LAN Realtek®
Maksymalna ilość portów USB 2.0: 6
Maksymalna ilość portów USB 3.x: 4
Porty USB na panelu tylnym: 4x USB 2.0 + 2x USB 3.0
Gniazda USB na płycie głównej: 1x USB 2.0 (2 porty) + 1x USB 3.0 (2 porty)
Port Wi-Fi: Nie
Port Bluetooth: Nie
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU fan header, System fan header, Front panel header, Front Panel Audio header (AAFP), Gniazdo modułu TPM, Clear CMOS jumper
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 226 x 185
Opakowanie: BOX
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Bundled Software:, - Norton Internet Security (wersja OEM), - LAN bandwidth management software, Support for Windows 10/11 64-bit
Parametry:
BIOS:
1 x 128 Mbit AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7,ACPI 5.0
To configure 7.1channel audio, access the audio software for audio settings, You can change the functionality of an audio jack using the audio software
Uwagi do karty graficznej:
- Support for DisplayPort 1.2 version and HDCP 2.3, - Support for HDMI 2.1 version and HDCP 2.3, - Support native HDMI 2.1 TMDS compatible ports, 1x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz, 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Uwagi do kontrolera SATA:
1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD
Uwagi do pamięci RAM:
(operate in non-ECC mode), data rate (speed), and number of DRAM modules, please refer to "Memory, Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, Support for Extreme Memory Profile (XMP), Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support List" on GIGABYTE's website for more information, The CPU and memory configuration may affect the supported memory types,
Uwagi do procesora:
L3 cache varies with CPU
Uwagi do złącz PCI:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16, - 1x PCI Express x1 slot, supporting PCIe 3.0 and running at x1, Chipset:, CPU:
Wbudowana karta graficzna:
Intel® HD Graphics
Wymiary [S x W] (mm):
226 x 185
Zintegrowana karta dźwiękowa:
Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Zintegrowany kontroler SATA:
Chipset: 2x SATA III 6Gb/s + 1x M.2
Złącza PCI Express x1:
1
Złącza PCI Express x16:
1
Zawiera baterię / akumulator:
Tak
Dane producenta
Gigabyte Technology Co. Ltd.
NO. 6, BAO CHIANG ROAD
231 Xindian Dist., New Taipei
Taiwan
