Uwagi do pamięci RAM: Ryzen 9000 Series Processors max. overclocking frequency:, - 1DPC 1R Max speed up to 8000+ MT/s, - 1DPC 2R Max speed up to 7200+ MT/s, Supports AMD POR Speed and JEDEC Speed, Supports Memory Overclocking and AMD EXPO, Supports Non-ECC, Un-buffered memory, Supports CUDIMM, Clock Driver bypass mode only
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0, 1
Uwagi do kontrolera SATA: M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260, devices, M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260, devices, M2_2 slot:, - Supports up to PCIe 4.0 x4, - Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors)
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI, VGA
Uwagi do karty graficznej: Support HDMI 2.1, maximum resolution of 4K 60Hz, Support VGA, max. res. of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz, Available only on processors featuring integrated graphics, Graphics specifications may vary depending on the CPU installed
Zintegrowana karta dźwiękowa: Realtek® ALC897 7.1-Channel High Definition Audio
Uwagi do złącz PCI: PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU), PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset), PCI_E1 slot:, - Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors), - Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors), - Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processors)
Port LAN: 1x 2,5 Gigabit LAN Realtek®8125D
Maksymalna ilość portów USB 2.0: 6
Maksymalna ilość portów USB 3.x: 7
Porty USB na panelu tylnym: 2x USB 2.0 + 4x USB 3.0
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
Port PS/2: Brak
Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU Fan, 2x System Fan, 2x Front Panel, Chassis Intrusion (JCI), 3x Addressable V2 RGB LED connector, RGB LED connector, Gniazdo modułu TPM, 4x EZ Debug LED, Flash BIOS Button, Clear CMOS button(s)
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 226 x 243,84
Opakowanie: BOX
Wyposażenie dodatkowe: SATA Cable, I/O Shield, Quick Installation Guide, European Union Regulatory Notice, 2x EZ M.2 Clip II, EZ M.2 Clip II Remover
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Support for Windows 11 64-bit
Available only on processors featuring integrated graphics, Graphics specifications may vary depending on the CPU installed, Support HDMI 2.1, maximum resolution of 4K 60Hz, Support VGA, max. res. of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz
Uwagi do kontrolera SATA:
- Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors), - Supports up to PCIe 4.0 x4, devices, M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260, M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260, M2_2 slot:
Uwagi do pamięci RAM:
- 1DPC 1R Max speed up to 8000+ MT/s, - 1DPC 2R Max speed up to 7200+ MT/s, Ryzen 9000 Series Processors max. overclocking frequency:, Supports AMD POR Speed and JEDEC Speed, Supports CUDIMM, Clock Driver bypass mode only, Supports Memory Overclocking and AMD EXPO, Supports non-ECC, un-buffered memory
Uwagi do procesora:
Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
Uwagi do złącz PCI:
- Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors), - Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processors), - Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors), PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU), PCI_E1 slot:, PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
226 x 243,84
Wyposażenie dodatkowe:
2x EZ M.2 Clip II, European Union Regulatory Notice, EZ M.2 Clip II Remover, I/O Shield, Quick Installation Guide, SATA cable
Zintegrowana karta dźwiękowa:
Realtek® ALC897 7.1-Channel High Definition Audio
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0, 1
Złącza PCI Express x1:
1
Złącza PCI Express x16:
1
Zawiera baterię / akumulator:
Tak
