Uwagi do pamięci RAM: Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme, Memory Profile (XMP) memory modules, The CPU and memory configuration may affect the supported memory types,, data rate (speed), and number of DRAM modules, please refer to "Memory, Support List" for more information
Zintegrowany kontroler SATA: Chipset+CPU: 2x SATA III 6Gb/s + 1x M.2 - RAID 0,1
Uwagi do kontrolera SATA: 1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type, 2280 SSDs:, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, RAID 0 and RAID 1 support for NVMe SSD storage devices, RAID 0 and RAID 1 support for SATA storage devices
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI, DisplayPort
Uwagi do karty graficznej: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3, Support native HDMI 2.1 TMDS compatible ports, 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 1.4 version, Graphics specifications may vary depending on CPU support
Zintegrowana karta dźwiękowa: Realtek® 8-Channel High Definition Audio CODEC
Uwagi do karty dźwiękowej: You can change the functionality of an audio jack using the audio software, To configure 7.1-channel audio, access the audio software for audio setting
Złącza PCI Express x16: 1
Uwagi do złącz PCI: 1 x PCI Express x16 slot, integrated in the CPU:, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, The PCIEX16 slot can only support a graphics card or an NVMe SSD
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Maksymalna ilość portów USB 2.0: 5
Maksymalna ilość portów USB 3.x: 6
Porty USB na panelu tylnym: 3x USB 2.0 + 1x USB 3.0 + 1x USB 3.0 Type-C + 1x USB 3.1
Gniazda USB na płycie głównej: 1x USB 2.0 (2 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax
Port Bluetooth: Bluetooth V5.3
Uwagi do WiFi / BT: Realtek® Wi-Fi 6E RTL8852CE, WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands, Support for 11ax 160MHz wireless standard, Actual data rate may vary depending on environment and equipment
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU fan header, 2x system fan headers, Addressable LED strip headers, RGB LED strip header, Front panel header, Front Panel Audio header (AAFP), Speaker header, Clear CMOS jumper, Złącze czujnika otwarcia obudowy, Przycisk Q-Flash Plus, 2x SMA antenna connectors (2T2R)
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 170 x 170
Opakowanie: BOX
Wyposażenie dodatkowe: Norton® Internet Security (OEM version), LAN bandwidth management software
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Windows® 11 64-bit, Windows® 10 64-bit
Parametry:
BIOS:
256 Mb UEFI AMI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
1x USB 2.0 (2 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
Gniazdo procesora:
Socket AM5
Gniazdo zasilania:
ATX (24-pin) + ATX12V (8-pin)
Ilość złącz pamięci DDR5:
2
Inne porty i gniazda:
2x SMA antenna connectors (2T2R), 2x system fan headers, Addressable LED strip headers, Clear CMOS jumper, CPU fan header, Front Panel Audio header (AAFP), Front panel header, Przycisk Q-Flash Plus, RGB LED strip header, Speaker header, Złącze czujnika otwarcia obudowy
Maksymalna ilość portów USB 2.0:
5
Maksymalna ilość portów USB 3.x:
6
Maksymalna wielkość pamięci:
128 GB
Obsługiwane typy procesorów:
AMD Ryzen™
Opakowanie:
BOX
Port Bluetooth:
Bluetooth V5.3
Port LAN:
1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Port PS/2:
Brak
Port równoległy (LPT):
Brak
Port szeregowy (COM):
Brak
Port Wi-Fi:
IEEE 802.11a/b/g/n/ac/ax
Porty USB na panelu tylnym:
3x USB 2.0 + 1x USB 3.0 + 1x USB 3.0 Type-C + 1x USB 3.1
To configure 7.1-channel audio, access the audio software for audio setting, You can change the functionality of an audio jack using the audio software
Uwagi do karty graficznej:
1x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Graphics specifications may vary depending on CPU support, Support for DisplayPort 1.4 version, Support for HDMI 2.1 version and HDCP 2.3, Support native HDMI 2.1 TMDS compatible ports
Uwagi do kontrolera SATA:
- AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, 1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type, 2280 SSDs:, RAID 0 and RAID 1 support for NVMe SSD storage devices, RAID 0 and RAID 1 support for SATA storage devices
Uwagi do pamięci RAM:
data rate (speed), and number of DRAM modules, please refer to "Memory, Memory Profile (XMP) memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support List" for more information, The CPU and memory configuration may affect the supported memory types,
Uwagi do procesora:
Support for: AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors
Uwagi do WiFi / BT:
Actual data rate may vary depending on environment and equipment, Realtek® Wi-Fi 6E RTL8852CE, Support for 11ax 160MHz wireless standard, WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
Uwagi do złącz PCI:
- AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, 1x PCI Express x16 slot, integrated in the CPU:, The PCIEX16 slot can only support a graphics card or an NVMe SSD
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
170 x 170
Wyposażenie dodatkowe:
Norton® Internet Security (OEM version), LAN bandwidth management software
Zintegrowana karta dźwiękowa:
Realtek® 8-Channel High Definition Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 2x SATA III 6Gb/s + 1x M.2 - RAID 0,1
Złącza PCI Express x16:
1
Zawiera baterię / akumulator:
Tak
Dane producenta
Gigabyte Technology Co. Ltd.
NO. 6, BAO CHIANG ROAD
231 Xindian Dist., New Taipei
Taiwan
