Uwagi do pamięci RAM: Ryzen 9000 Series Processors max. overclocking frequency:, - 1DPC 1R Max speed up to 8000+ MT/s, - 1DPC 2R Max speed up to 6400+ MT/s, - 2DPC 1R Max speed up to 6400+ MT/s, - 2DPC 2R Max. speed up to 5600+ MT/s, Supports AMD POR Speed and JEDEC Speed, Supports Memory Overclocking and AMD EXPO, Supports Non-ECC, Un-buffered memory, Supports CUDIMM, Clock Driver bypass mode only
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2
Uwagi do kontrolera SATA: M.2_1 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260 devices, M.2_2 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260 devices
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI
Uwagi do karty graficznej: Support HDMI 2.1, maximum resolution of 4K 60Hz, Available only on processors featuring integrated graphics, Graphics specifications may vary depending on the CPU installed.
Zintegrowana karta dźwiękowa: Realtek® ALC897 7.1-Channel High Definition Audio
Uwagi do złącz PCI: PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU), PCI_E2 Gen PCIe 3.0 supports up to x4 (From Chipset)
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek® RTL8125D)
Maksymalna ilość portów USB 2.0: 8
Maksymalna ilość portów USB 3.x: 7
Porty USB na panelu tylnym: 4x USB 2.0 + 2x USB 3.0 + 1x USB 3.1 + 1x USB 3.1 Type-C
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax
Port Bluetooth: Bluetooth V5.3
Uwagi do WiFi / BT: Wi-Fi 6E Solution, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (160MHz) up to 2.4Gbps, Supports Bluetooth® 5.3, FIPS, FISMA, Wi-Fi 6E 6GHz may depend on every country's regulations and will be ready, in Windows 11, Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11
Port PS/2: Brak
Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU Fan, Combo Fan (Pump_Sys Fan), 3x System Fan, EZ Conn-header (JAF_1), 2x Front Panel, Złącze czujnika otwarcia obudowy, Tuning Controller Connector, 3x Addressable V2 RGB LED connector, RGB LED connector, Gniazdo modułu TPM, 4x EZ Debug LED, 2x Antenna Ports
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 243,84 x 243,84
Opakowanie: BOX
Wyposażenie dodatkowe: SATA Cable, EZ Wi-Fi antenna, Quick Installation Guide, European Union Regulatory Notice, EZ M.2 Clip II, EZ M.2 Clip II Remover, 1 to 2 EZ Conn-Cable (V1)
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Support for Windows 11 64-bit
Available only on processors featuring integrated graphics, Graphics specifications may vary depending on the CPU installed., Support HDMI 2.1, maximum resolution of 4K 60Hz
Uwagi do kontrolera SATA:
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4, M.2_2 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260 devices
Uwagi do pamięci RAM:
- 1DPC 1R Max speed up to 8000+ MT/s, - 1DPC 2R Max speed up to 6400+ MT/s, - 2DPC 1R Max speed up to 6400+ MT/s, - 2DPC 2R Max. speed up to 5600+ MT/s, Ryzen 9000 Series Processors max. overclocking frequency:, Supports AMD POR Speed and JEDEC Speed, Supports CUDIMM, Clock Driver bypass mode only, Supports Memory Overclocking and AMD EXPO, Supports non-ECC, un-buffered memory
Uwagi do procesora:
Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
Uwagi do WiFi / BT:
Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11, in Windows 11, Supports Bluetooth® 5.3, FIPS, FISMA, Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps, The Wireless module is pre-installed in the M.2 (Key-E) slot, Wi-Fi 6E 6GHz may depend on every country's regulations and will be ready (15490), Wi-Fi 6E Solution
Uwagi do złącz PCI:
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU), PCI_E2 Gen PCIe 3.0 supports up to x4 (From Chipset)
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
243,84 x 243,84
Wyposażenie dodatkowe:
1 to 2 EZ Conn-Cable (V1), European Union Regulatory Notice, EZ M.2 Clip II, EZ M.2 Clip II Remover, EZ Wi-Fi antenna, Quick Installation Guide, SATA cable
Zintegrowana karta dźwiękowa:
Realtek® ALC897 7.1-Channel High Definition Audio
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2
Złącza PCI Express x16:
2
Zawiera baterię / akumulator:
Tak
