Uwagi do pamięci RAM: Ryzen 9000 Series Processors max. overclocking frequency:, - 1DPC 1R Max speed up to 8400+ MT/s, - 1DPC 2R Max speed up to 8000+ MT/s
Zintegrowany kontroler SATA: Chipset+CPU: 2x SATA III 6Gb/s - RAID 0,1 + 2x M.2 - RAID 0,1
Uwagi do kontrolera SATA: - M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 ,, supports 2280 devices, - M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 ,, supports 2280 devices, M.2_1 slot:, - Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors), - Supports up to PCIe 4.0 x4 (For Ryzen 8000 Series processors), M.2_2 slot:, - Supports up to PCIe 4.0 x4, 2280 devices
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI
Uwagi do karty graficznej: Support HDMITM 2.1 with FRL port, supporting a max. resolution of 8K 60Hz, Available only on processors featuring integrated graphics, Graphics specifications may vary depending on the CPU installed
Zintegrowana karta dźwiękowa: Realtek® ALC 4080 7.1-Channel USB High Performance Audio CODEC
Uwagi do złącz PCI: - PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), PCI_E1 slot:, - Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors), - Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors), - Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor)
Port LAN: 1x 5 Gigabit LAN Realtek® 8126
Maksymalna ilość portów USB 2.0: 4
Maksymalna ilość portów USB 3.x: 7
Porty USB na panelu tylnym: 2x USB 3.0 + 3x USB 3.1 + 1x USB 3.2 Type-C
Gniazda USB na płycie głównej: 1x USB 2.0 (2 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.1 Type-C (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth: Bluetooth V5.4
Uwagi do WiFi / BT: Wi-Fi 7, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (320MHz) up to 5.8Gbps, Supports Bluetooth 5.4, MLO, 4KQAM, 6GHz band support may depend on every country's regulations and Wi-Fi 7, will be ready in Windows 11 version 24H2, The Bluetooth version may be updated, please refer to the Wi-Fi chipset, vendor's website for details, Bluetooth 5.4 will be ready in Windows 11 version 24H2
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU Fan, Combo Fan (Pump_Sys Fan), System Fan, EZ Conn-header (JAF_1), Złącze czujnika otwarcia obudowy, Addressable V2 RGB LED connector, Gniazdo modułu TPM, 4x EZ Debug LED, Clear CMOS button(s), Flash BIOS Button, 2x Antenna Ports
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 170 x 170
Opakowanie: BOX
Wyposażenie dodatkowe: SATA Cable, Cable Sticker, EZ Wi-Fi antenna, Quick Installation Guide, European Union Regulatory Notice, 3x M.2 Screws, ARGB Extension Cable, 1 to 3 EZ Conn-Cable (V2), EZ Front Panel cable
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Support for Windows 11 64-bit
Available only on processors featuring integrated graphics, Graphics specifications may vary depending on the CPU installed, Support HDMITM 2.1 with FRL port, supporting a max. resolution of 8K 60Hz
Uwagi do kontrolera SATA:
- M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 ,, - M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 ,, - Supports up to PCIe 4.0 x4 (For Ryzen 8000 Series processors), - Supports up to PCIe 4.0 x4, 2280 devices, - Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors), M.2_1 slot:, M.2_2 slot:, supports 2280 devices
Uwagi do pamięci RAM:
- 1DPC 1R Max speed up to 8400+ MT/s, - 1DPC 2R Max speed up to 8000+ MT/s, Ryzen 9000 Series Processors max. overclocking frequency:
Uwagi do procesora:
Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
Uwagi do WiFi / BT:
6GHz band support may depend on every country's regulations and Wi-Fi 7 (30768), Bluetooth 5.4 will be ready in Windows 11 version 24H2, Supports Bluetooth 5.4, MLO, 4KQAM, Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (320MHz) up to 5.8Gbps, The Bluetooth version may be updated, please refer to the Wi-Fi chipset, The Wireless module is pre-installed in the M.2 (Key-E) slot, vendor's website for details (15357), Wi-Fi 7, will be ready in Windows 11 version 24H2
Uwagi do złącz PCI:
- PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), - Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor), - Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors), - Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors), PCI_E1 slot:
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
170 x 170
Wyposażenie dodatkowe:
1 to 3 EZ Conn-Cable (V2), 3x M.2 Screws, ARGB Extension Cable, Cable Sticker, European Union Regulatory Notice, EZ Front Panel Cable, EZ Wi-Fi antenna, Quick Installation Guide, SATA cable
Zintegrowana karta dźwiękowa:
Realtek® ALC4080 7.1-Channel USB High Performance Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 2x SATA III 6Gb/s - RAID 0,1 + 2x M.2 - RAID 0,1
Złącza PCI Express x16:
1
Zawiera baterię / akumulator:
Tak
